Showing 1 to 74 of 74 entries (filtered from 74 total entries)

Series	Data Sheet	Inductance	Tolerance	Current Rating	DC Resistance - DCR	Shielding	Package / Case	Size / Dimension	Height - Seated	Applications
PIW-6D	https://www.meritekusa.com/wp-content/uploads/2025/06/Mertiek-Spec-PIW-6D-Series-5b-250502.pdf	1.2µH ~ 1500µH	±20%	0.13A ~ 8.2A	6.9mΩ ~ 4780mΩ	Shielded	0628, 0728, 0730, 0732, 0745, 1045, 1255, 1265	6.2mm x 6.2mm, 7.2mm x 7.2mm, 10.4mm x 10.4mm, 12.8mm x 12.8mm	3mm, 3.2mm, 3.4mm, 4.8mm, 5.85mm, 6.85mm, 7.85mm	General Purpose
PIW-6B	https://www.meritekusa.com/wp-content/uploads/2025/08/Meritek-Spec-PIW-6B-Series-4b-241001.pdf	1.0µH ~ 10000µH	±20%, ±30%	0.02A ~ 5A	40mΩ ~ 32800mΩ	Shielded	0402, 0804, 1206	6.6mm x 4.45mm, 12.95mm x 9.4mm, 18.54mm x 15.24mm	2.92mm, 5.08mm, 7.62mm	General Purpose
PIW-1608B65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-1608B65.pdf	1µH ~ 10µH	±20%, ±30%	0.25A ~ 0.9A	120mΩ ~ 930mΩ	Shielded	1608B	1.6mm x 0.9mm	0.95mm	General Purpose
SIE-MM17	https://www.meritekusa.com/wp-content/uploads/2019/11/Signal-Inductor-Wire-Wound-Ceramic-Chip-SIE-MM17.pdf	1.5nH ~ 120nH	±2%, ±5%	0.11A ~ 1A	30mΩ ~ 2660mΩ	UnShielded	0402	1.27mm x 0.76mm	0.61mm	General Purpose
PIW-8040M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-8040M65.pdf	0.5µH ~ 470µH	±10%, ±15%, ±20%, ±30%	0.63A ~ 12A	5.5mΩ ~ 1300mΩ	Shielded	8040	8mm x 8mm	3.7mm, 4.2mm	AEC-Q200
PIW-804065	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-804065.pdf	1µH ~ 680µH	±20%	0.5A ~ 8A	8.2mΩ ~ 2200mΩ	Shielded	8040	8mm x 8mm	3.7mm, 4.2mm	General Purpose
PIW-6045M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-6045M65.pdf	0.36µH ~ 470µH	±10%, ±15%, ±20%, ±30%	0.4A ~ 9A	4.8mΩ ~ 2050mΩ	Shielded	6045	6mm x 6mm	4.2mm	AEC-Q200
PIW-604565	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-604565.pdf	0.36µH ~ 680µH	±20%	0.3A ~ 8.5A	4.8mΩ ~ 2900mΩ	Shielded	6045	6mm x 6mm	4.2mm	General Purpose
PIW-6028M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-6028M65.pdf	1µH ~ 470µH	±20%, ±30%	0.32A ~ 5.2A	10mΩ ~ 2250mΩ	Shielded	6028	6mm x 6mm	2.6mm	AEC-Q200
PIW-602865	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-602865.pdf	1µH ~ 47µH	±20%, ±30%	1.06A ~ 5.2A	10mΩ ~ 280mΩ	Shielded	6028	6mm x 6mm	2.6mm	General Purpose
PIW-6020M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-6020M65.pdf	0.8µH ~ 33µH	±10%, ±15%, ±20%, ±30%	1.3A ~ 5.5A	16mΩ ~ 340mΩ	Shielded	6020	6mm x 6mm	1.8mm	AEC-Q200
PIW-602065	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-602065.pdf	0.8µH ~ 33µH	±10%, ±15%, ±20%, ±30%	1.3A ~ 5.5A	16mΩ ~ 340mΩ	Shielded	6020	6mm x 6mm	1.8mm	General Purpose
PIW-5040M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-5040M65.pdf	0.47µH ~ 220µH	±10%, ±15%, ±20%, ±30%	0.55A ~ 9A	6.5mΩ ~ 1500mΩ	Shielded	5040	4.95mm x 4.95mm	3.9mm	AEC-Q200
PIW-504065	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-504065.pdf	0.6µH ~ 220µH	±10%, ±15%, ±20%, ±30%	0.55A ~ 8A	8mΩ ~ 1500mΩ	Shielded	5040	4.95mm x 4.95mm	3.9mm	General Purpose
PIW-5020M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-5020M65.pdf	0.22µH ~ 47µH	±20%, ±30%	0.7A ~ 8A	9.8mΩ ~ 460mΩ	Shielded	5020	5mm x 5mm	1.8mm	AEC-Q200
PIW-502065	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-502065.pdf	1µH ~ 470µH	±20%, ±30%	0.7A ~ 4.1A	20mΩ ~ 460mΩ	Shielded	5020	5mm x 5mm	1.8mm	General Purpose
PIW-5012M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-5012M65.pdf	1µH ~ 15µH	±20%	1.35A ~ 4A	57mΩ ~ 600mΩ	Shielded	5012	5mm x 5mm	1mm	AEC-Q200
PIW-5010M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-5010M65.pdf	1µH ~ 22µH	±20%	3.5A ~ 0.9A	54mΩ ~ 590mΩ	Shielded	5010	5mm x 5mm	0.9mm	AEC-Q200
PIW-40EM63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-40EM63-3b-230615.pdf	0.22µH ~ 10µH	±20%	2.4A ~ 9.5A	9.5mΩ ~ 180mΩ	Shielded	4040	4mm x 4mm	2.0mm	AEC-Q200
PIW-40C63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-40C63-3b-230615.pdf	0.47µH ~ 10µH	±20%	1.6A ~ 6A	28mΩ ~ 280mΩ	Shielded	4040	4mm x 4mm	1.2mm	General Purpose
PIW-40B63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-40B63-3b-230615.pdf	0.47µH ~ 10µH	±20%	1.4A ~ 4.5A	38mΩ ~ 440mΩ	Shielded	4040	4mm x 4mm	1mm	General Purpose
PIW-40A63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-40A63-3b-230615.pdf	0.47µH ~ 10µH	±20%	1.2A ~ 3.5A	60mΩ ~ 700mΩ	Shielded	4040	4mm x 4mm	0.8mm	General Purpose
PIW-4030M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-4030M65.pdf	0.68µH ~ 47.0µH	±20%	0.95A ~ 6.8A	10000mΩ ~ 445000mΩ	Shielded	4030	4mm x 4mm	3.0mm	AEC-Q200
PIW-4020M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-4020M65.pdf	1µH ~ 100µH	±20%	3.8A ~ 0.35A	20mΩ ~ 1400mΩ	Shielded	4020	4mm x 4mm	1.8mm	AEC-Q200
PIW-4018M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-4018M65.pdf	1µH ~ 68µH	±20%, ±30%	0.32A ~ 3.2A	27mΩ ~ 1000mΩ	Shielded	4018	4mm x 4mm	1.6mm	AEC-Q200
PIW-4018B65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-4018B65.pdf	0.47µH ~ 220µH	±20%	0.275A ~ 6A	15mΩ ~ 3800mΩ	Shielded	4018B	4mm x 4mm	1.8mm	General Purpose
PIW-401865	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-401865.pdf	1µH ~ 220µH	±20%	0.3A ~ 3.7A	0.027mΩ ~ 3.000mΩ	Shielded	4018	4mm x 4mm	1.8mm	General Purpose
PIW-401565	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-401565.pdf	1µH ~ 15µH	±20%	1.1A ~ 3.7A	0.033mΩ ~ 0.230mΩ	Shielded	4015	4mm x 4mm	1.5mm	General Purpose
PIW-4012M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-4012M65.pdf	0.47µH ~ 47µH	±20%	0.65A ~ 5.5A	25mΩ ~ 1100mΩ	Shielded	4012	4mm x 4mm	1mm	AEC-Q200
PIW-401265	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-401265.pdf	1µH ~ 22µH	±20%, ±30%	0.72A ~ 2.5A	0.042mΩ ~ 0.4mΩ	Shielded	4012	4mm x 4mm	1.2mm	General Purpose
PIW-4010M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-4010M65.pdf	1µH ~ 22µH	±20%	0.8A ~ 3.5A	60mΩ ~ 600mΩ	Shielded	4010	4mm x 4mm	0.9mm	AEC-Q200
PIW-401065	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-401065.pdf	1µH ~ 22µH	±20%, ±30%	0.8A ~ 2.3A	56mΩ ~ 570mΩ	Shielded	4010	4mm x 4mm	1mm	General Purpose
PIW-3612M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-3612M65.pdf	10µH	±20%	1.2A	290mΩ	Shielded	3612	3.6mm x 3.6mm	1mm	AEC-Q200
PIW-3225CM65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-3225CM65.pdf	0.33µH ~ 22µH	±20%	0.8A ~ 5A	19mΩ ~ 660mΩ	Shielded	3225C	3.2mm x 2.5mm	1mm	AEC-Q200
PIW-30DM63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-30DM63-3b-230615.pdf	0.47µH ~ 10µH	±20%	1.6A ~ 5.8A	25mΩ ~ 370mΩ	Shielded	3030	3mm x 3mm	1.2mm	AEC-Q200
PIW-30D63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-30D63-3b-230615.pdf	0.47µH ~ 10µH	±20%	1.5A ~ 5.5A	30mΩ ~ 350mΩ	Shielded	3030	3mm x 3mm	1.2mm	General Purpose
PIW-30CM63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-30CM63-3b-230615.pdf	0.3µH ~ 4.7µH	±20%	2A ~ 6.4A	22mΩ ~ 195mΩ	Shielded	3030	3mm x 3mm	1.2mm	AEC-Q200
PIW-30C63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-30C63-3b-230615.pdf	0.33µH ~ 10µH	±20%	1.4A ~ 5.5A	20mΩ ~ 290mΩ	Shielded	3030	3mm x 3mm	1.2mm	General Purpose
PIW-30B63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-30B63-3b-230615.pdf	0.47µH ~ 10µH	±20%	1A ~ 3.5A	33mΩ ~ 360mΩ	Shielded	3030	3mm x 3mm	1mm	General Purpose
PIW-30A63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-30A63-3b-230615.pdf	0.24µH ~ 10µH	±20%	1A ~ 5A	35mΩ ~ 860mΩ	Shielded	3030	3mm x 3mm	0.8mm	General Purpose
PIW-3015M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-3015M65.pdf	0.24µH ~ 100µH	±20%	0.4A ~ 5A	13mΩ ~ 3400mΩ	Shielded	3015	3mm x 3mm	1.3mm	AEC-Q200
PIW-301565	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-301565.pdf	1µH ~ 68µH	±20%, ±30%	0.35A ~ 2.2A	30mΩ ~ 2000mΩ	Shielded	3015	3mm x 3mm	1.5mm	General Purpose
PIW-3012M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-3012M65.pdf	0.22µH ~ 47µH	±20%	0.65A ~ 6.2A	15mΩ ~ 1500mΩ	Shielded	3012	3mm x 3mm	1mm	AEC-Q200
PIW-301265	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-301265.pdf	1µH ~ 47µH	±20%, ±30%	0.4A ~ 2.2A	42mΩ ~ 1450mΩ	Shielded	3012	3mm x 3mm	1.2mm	General Purpose
PIW-3010M65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-3010M65.pdf	1µH ~ 47µH	±20%	0.45A ~ 3.4A	56mΩ ~ 1900mΩ	Shielded	3010	3mm x 3mm	0.9mm	AEC-Q200
PIW-301065	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-301065.pdf	1µH ~ 22µH	±20%, ±30%	0.75A ~ 2.5A	55mΩ ~ 750mΩ	Shielded	3010	3mm x 3mm	1mm	General Purpose
PIW-2520C65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-2520C65.pdf	1µH ~ 22µH	±20%, ±30%	0.45A ~ 2.2A	73mΩ ~ 1200mΩ	Shielded	2520C	2.5mm x 2mm	1.2mm	General Purpose
PIW-2520BM65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-2520BM65.pdf	0.47µH ~ 15µH	±20%	0.8A ~ 3A	29mΩ ~ 770mΩ	Shielded	2520B	2.5mm x 2mm	0.9mm	AEC-Q200
PIW-2520AM65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-2520AM65.pdf	0.47µH ~ 6.8µH	±20%	1A ~ 2.6A	46mΩ ~ 530mΩ	Shielded	2520A	2.5mm x 2mm	0.7mm	AEC-Q200
PIW-2520A65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-2520A65.pdf	0.47µH ~ 10µH	±20%	0.45A ~ 1.45A	96mΩ ~ 1110mΩ	Shielded	2520A	2.5mm x 2mm	0.8mm	General Purpose
PIW-2016CM65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-2016CM65.pdf	0.33µH ~ 22µH	±20%	0.4A ~ 3.5A	25mΩ ~ 1650mΩ	Shielded	2016C	2mm x 1.6mm	1mm	AEC-Q200
PIW-2016BM65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-2016BM65.pdf	0.24µH ~ 22µH	±20%	0.5A ~ 5.2A	20mΩ ~ 1800mΩ	Shielded	2016B	2mm x 1.6mm	0.9mm	AEC-Q200
PIW-2016B65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-2016B65.pdf	0.47µH ~ 22µH	±20%, ±30%	0.3A ~ 2.6A	44mΩ ~ 2000mΩ	Shielded	2016B	2mm x 1.6mm	1mm	General Purpose
PIW-2016AM65	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW-2016AM65.pdf	0.33µH ~ 3.3µH	±20%	1.5A ~ 3A	33mΩ ~ 230mΩ	Shielded	2016A	2mm x 1.6mm	0.7mm	AEC-Q200
PIW10-C63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW10-C63-3b-230615.pdf	0.47µH ~ 33µH	±20%	0.6A ~ 5.40A	19mΩ ~ 1400mΩ	Shielded	1210	3.2mm x 2.5mm	1.2mm	General Purpose
PIW10-B63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW10-B63-3b-230615.pdf	0.24µH ~ 10µH	±20%	1.6A ~ 6.1A	25mΩ ~ 335mΩ	Shielded	1210	3.2mm x 2.5mm	1mm	General Purpose
PIW10-A63	https://www.meritekusa.com/wp-content/uploads/2023/10/PIW10-A63.pdf	0.24µH ~ 10µH	±20%	1.1A ~ 4.5A	40mΩ ~ 760mΩ	Shielded	1210	3.2mm x 2.5mm	0.8mm	General Purpose
PIW08-CM63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW08-CM63-3b-230615.pdf	0.24µH ~ 10µH	±20%	1.4A ~ 10A	18mΩ ~ 450mΩ	Shielded	1008	2.5mm x 2mm	1.2mm	AEC-Q200
PIW08-BM63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW08-BM63-3b-230615.pdf	0.24µH ~ 4.7µH	±20%	1.7A ~ 5.6A	23mΩ ~ 260mΩ	Shielded	1008	2.5mm x 2mm	1mm	AEC-Q200
PIW08-B63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW08-B63-3b-230615.pdf	0.24µH ~ 10µH	±20%	1A ~ 5.5A	18mΩ ~ 530mΩ	Shielded	1008	2.5mm x 2mm	1mm	General Purpose
PIW08-A63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW08-A63-3b-230615.pdf	0.24µH ~ 4.7µH	±20%	1.2A ~ 4.8A	28mΩ ~ 360mΩ	Shielded	1008	2.5mm x 2mm	0.8mm	General Purpose
PIW06-CM63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW06-CM63-3b-230615.pdf	0.47µH ~ 4.7µH	±20%	1.5A ~ 4.3A	34mΩ ~ 280mΩ	Shielded	0806	2mm x 1.6mm	1.2mm	AEC-Q200
PIW06-BM63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW06-BM63-3b-230615.pdf	0.47µH ~ 10µH	±20%	0.9A ~ 4A	42mΩ ~ 800mΩ	Shielded	0806	2mm x 1.6mm	1mm	AEC-Q200
PIW06-B63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW06-B63-3b-230615.pdf	0.24µH ~ 10µH	±20%	0.8A ~ 5.7A	15mΩ ~ 680mΩ	Shielded	0806	2mm x 1.6mm	1mm	General Purpose
PIW06-A63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW06-A63-3b-230615.pdf	0.24µH ~ 10µH	±20%	0.8A ~ 4.5A	30mΩ ~ 800mΩ	Shielded	0806	2mm x 1.6mm	0.8mm	General Purpose
PIW05-B63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW05-B63-3b-230615.pdf	0.24µH ~ 22µH	±20%	0.5A ~ 2.4A	22mΩ ~ 1700mΩ	Shielded	0805	2mm x 1.2mm	1mm	General Purpose
PIW05-A63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW05-A63-3b-230615.pdf	0.24µH ~ 10µH	±20%	0.033A ~ 2.16A	28mΩ ~ 1800mΩ	Shielded	0805	2mm x 1.2mm	0.8mm	General Purpose
PIW04-A63	https://www.meritekusa.com/wp-content/uploads/2023/10/PIW04-A63.pdf	0.24µH ~ 10µH	±20%	0.45A ~ 3.5A	40mΩ ~ 2000mΩ	Shielded	0504	1.2mm x 1mm	0.8mm	General Purpose
PIW03-A63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW03-A63-3b-230615.pdf	0.24µH ~ 10µH	±20%	0.35A ~ 2A	75mΩ ~ 2100mΩ	Shielded	0603	1.6mm x 0.8mm	0.8mm	General Purpose
PIW08-C63	https://www.meritekusa.com/wp-content/uploads/2023/08/PIW08-C63-3b-230615.pdf	0.24µH ~ 22µH	±20%	0.6A ~ 6A	19mΩ ~ 1000mΩ	Shielded	1008	2.5mm x 2mm	1.2mm	General Purpose
PIW-S65	https://www.meritekusa.com/wp-content/uploads/2024/10/Meritek-series-PIW-S65.pdf	0.56µH ~ 1000µH	±20%, ±30%	0.17A ~ 7.15A	7mΩ ~ 5200mΩ	Shielded	3015, 4018, 4030, 5040, 6045, 8040	3mm x 3mm, 4mm x 4mm, 5mm x 5mm, 6mm x 6mm, 8mm x 8mm	1.5mm, 1.85mm, 4.1mm, 4.5mm, 4.2mm, 3mm	General Purpose
PIW-67	https://www.meritekusa.com/wp-content/uploads/2024/08/Mertiek-Spec-PIW-67-Series.pdf	1.3µH ~ 1000µH	±20%, +40/-20%	0.4A ~ 9.8A	7.0mΩ ~ 1820mΩ	Shielded	124P, 125P, 127P	12.3mm x 12.3mm	4.8mm, 60mm, 80mm	General Purpose
PIW-62	https://www.meritekusa.com/wp-content/uploads/2024/08/Mertiek-Spec-PIW-62-Series.pdf	0.8µH ~ 1000µH	±10%, ±20%, ±30%	0.22A ~ 9.5A	4.3mΩ ~ 4100mΩ	Shielded	104, 105	10.3mm x 10.4mm, 10.3mm x 10.5mm	4mm, 5.1mm	General Purpose
PIW-61	https://www.meritekusa.com/wp-content/uploads/2024/08/Mertiek-Spec-PIW-61-Series.pdf	0.8µH ~ 1000µH	±30%	0.52A ~ 9A	3.7mΩ ~ 2920mΩ	Shielded	5D3, 103, 104, 105	6.2mm x 6.3mm, 10.3mm x 10.4mm	3mm, 4mm, 5mm	General Purpose
