KHz Crystal-Tuning Fork

KHz Crystal-Tuning Fork

Sort by Default
- Default
- Name
- Price
- Date
- Custom
- Popularity (sales)
- Average rating
- Relevance
- Random
- Product ID

Display -1 Products per page

Showing 1 to 13 of 13 entries (filtered from 13 total entries)

Series	Data Sheet	Frequency	Load Capacitance	Frequency Tolerance	ESR (Equivalent Series Resistance)	Operating Temperature	Package/Case	Applications
MXT7	https://www.meritekusa.com/wp-content/uploads/2018/06/32.768kHz-4-Pad-SMD-Leaded-MXT7-Series.pdf	32.768KHz	7pF ~ 12.5pF	±10ppm ~ ±30ppm	65KΩ	-40ºC ~ 85ºC	4-SMD (6.9mm x 1.4mm)	General Purpose
MXTV	https://www.meritekusa.com/wp-content/uploads/2025/07/Meritek-Spec-MXTV-Series-5b-250701.pdf	32.768KHz	6pF ~ 30pF	±5ppm ~ ±100ppm	50KΩ	-40ºC ~ 85ºC	4-SOJ	General Purpose
MXTU	https://www.meritekusa.com/wp-content/uploads/2018/06/32.768kHz-Cylindrical-Leaded-6.2x2.1mm-MXTU-Series.pdf	32.768KHz	6pF ~ 12.5pF	±10ppm ~ ±20ppm	35KΩ	-10ºC ~ 60ºC	Cylindrical Can - TH	General Purpose
MXTT	https://www.meritekusa.com/wp-content/uploads/2018/06/32.768kHz-Cylindrical-Leaded-5.1x1.5mm-MXTT-Series.pdf	32.768KHz	6pF ~ 12.5pF	±10ppm ~ ±20ppm	40KΩ	-10ºC ~ 60ºC	Cylindrical Can - TH	General Purpose
MXTR	https://www.meritekusa.com/wp-content/uploads/2018/06/Cylindrical-SMD-Leaded-MXTR-Series.pdf	4MHz ~ 70MHz	10pF ~ 32pF	±30ppm ~ ±50ppm	150Ω	-40ºC ~ 85ºC	Cylindrical Can - SMD	General Purpose
MXTQ	https://www.meritekusa.com/wp-content/uploads/2024/11/Meritek-Spec-MXTQ-Series.pdf	32.768KHz	6pF ~ 30pF	±10ppm ~ ±30ppm	50KΩ	-40ºC ~ 85ºC	4-SOJ (5.5mm pitch)	General Purpose
MXTP	https://www.meritekusa.com/wp-content/uploads/2018/06/32.768kHz-Cylindrical-Leaded-8.3x3.2mm-MXTP-Series.pdf	32.768KHz	6pF ~ 12.5pF	±10ppm ~ ±20ppm	30KΩ	-10ºC ~ 60ºC	Cylindrical Can - TH	General Purpose
MXTO	https://www.meritekusa.com/wp-content/uploads/2024/11/Meritek-Spec-MXTO-Series.pdf	32.768KHz	6pF ~ 30pF	±10ppm ~ ±100ppm	50KΩ	-40ºC ~ 85ºC	Cylindrical Can - SMD	General Purpose
MXT5	https://www.meritekusa.com/wp-content/uploads/2024/04/MXT5-Series.pdf	32.768KHz	6pF ~ 12.5pF	±10ppm ~ ±30ppm	70KΩ	-40ºC ~ 85ºC	2-SMD (4.9mm x 1.8mm)	General Purpose
MXT4	https://www.meritekusa.com/wp-content/uploads/2024/04/MXT4-Series.pdf	32.768KHz	6pF ~ 12.5pF	±10ppm ~ ±30ppm	70KΩ	-40ºC ~ 85ºC	2-SMD (4.1mm x 1.5mm)	General Purpose
MXT3	https://www.meritekusa.com/wp-content/uploads/2024/04/MXT3-Series.pdf	32.768KHz	6pF ~ 12.5pF	±10ppm ~ ±50ppm	70KΩ	-40ºC~ 125ºC	2-SMD (3.2mm x 1.5mm)	General Purpose
MXT2	https://www.meritekusa.com/wp-content/uploads/2024/04/MXT2-Series.pdf	32.768KHz	6pF ~ 12.5pF	±10ppm ~ ±50ppm	90KΩ	-40ºC ~ 85ºC	2-SMD (2.0mm x 1.2mm)	General Purpose
MXT1	https://www.meritekusa.com/wp-content/uploads/2024/04/MXT1-Series.pdf	32.768KHz	6pF ~ 12.5pF	±10ppm ~ ±50ppm	70KΩ	-40ºC ~ 85ºC	2-SMD (1.6mm x 1.0mm)	General Purpose
