PIW-4012M65
Description
Product Characteristics
| P/N Series | PIW-4012M65 |
| Description | Wirewound Inductor SMD AEC-Q200 |
| Inductance | 0.47µH ~ 47µH |
| Tolerance | ±20% |
| Current Rating (A) | 0.48A ~ 5.0A |
| DC Resistance (DCR) Max | 25mΩ ~ 1100mΩ |
| Q Test Frequency | 100KHz |
| Package/Case | 4012 |
| Applications | AEC-Q200 |
Environmental Classifications
| RoHS Status | RoHS Compliant |
| Reach Status | REACH Unaffected |
