SIM10-20AE
Description
Product Characteristics
| P/N Series | SIM10-20AE |
| Description | High Current Molded SMD Power Inductor |
| Inductance | 0.33μH ~ 1.5μH |
| Tolerance | ±20% |
| Current Rating | 5.3A ~ 8.5A |
| DC Resistance – DCR | 8mΩ ~ 25.8mΩ |
| Shielding | Shielded |
| Package / Case | 1210 |
| Size / Dimension (mm) | 3.20×2.50 |
| Height – Seated (mm) | 1.8 |
| Applications | General Purpose |
Environmental Classifications
| RoHS Status | RoHS Compliant |
| Reach Status | REACH Unaffected |
