Part Number
|
PID-07452
|
|
Description
|
Power Inductor Dual-Winding Shielded
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
Size Code125, 12.0×12.0x6.5mm
| Nominal Inductance (μH) | 2.5 ~ 1000 μH |
| Irms (A) | 2.17 ~ 0.14 |
| Isat (A) | 6.3 ~ 0.31 |
| Operating Temperature | -40ºC~ 125 ºC |
| DC Resistance (Max.) | 0.036 ~ 10.8Ω |
| Feature | Magnetically Shielded Construction Against Radiation |
| Applications | Parallel, Series, Dual-Inductor and Transformer |
| Product Code | PIW ,Power Inductor Series, Wire Wound Type |
| Test Frequency (Hz) | 0.1V/100K |
| Size Code | 125, 12.0×12.0x6.5mm |
| Series Code | 52 Power Inductor Dual Winding Type, Internal control or project reference |
