PIM-0402BA2 series
Description
Product Characteristics
| P/N Series | PIM-0402BA2 |
| Description | High Current, Low DCR Molded Power Inductor |
| Inductance | 0.1μH ~ 1.8μH |
| Tolerance | ±20% |
| Current Rating | 5.2A ~ 18A |
| DC Resistance – DCR | 2.2mΩ ~ 25mΩ |
| Shielding | Shielded |
| Package / Case | 0402B |
| Size / Dimension (mm) | 4.4×4.4 |
| Height – Seated (mm) | 1.9 |
| Applications | General Purpose |
Environmental Classifications
| RoHS Status | RoHS Compliant |
| Reach Status | REACH Unaffected |
