Part Number
|
4-SOJ
|
|
Description
|
Low Profile, Heat Resistant
|
| Meritek Series | Crystal Unit |
| Internal Connection | Please see details in the PDF |
|
Additional Information
|
Product Characteristics
| Frequency | 32.768 kHz |
| Load Capacitance | 12.5 pF |
| Frequency Tolerance | +/-20ppm |
| Operating Temperature | -40 ~ +85C |
| Storage Temperature | -55 ~ +125C |
| Turnover Temperature | 25 ±5C |
| Frequency Temperature Curve | -0.035 ±0.006ppm/°C |
| Aging (at 25ºC) | ±3 max. ppm / year |
| Mounting Type | Surface Mount |
| ESR – max. | 50kΩ |
| Drive Level – max. | 1.0µW |
| Insulation Resistance (@100Vdc +/-15V) | 500 min. MΩ |
| Shunt Capactiance (C0) | 1.9 typ. pF |
| Applications | Wired Network, Mobile Communication, Wearables, Handheld Electronic Devices, Computer Clock |
| Dimensions | 10.40mm x 4.06mm x 3.60mm |
| Series | MXTV |
| Part Status | Active |
