Showing 1 to 5 of 5 entries (filtered from 5 total entries)

Series Data Sheet Diode TypeVoltage - Peak Reverse (Max)Current - Average Rectified (Io)Voltage - Forward (Vf) (Max)Peak Forward Surge Current, IFSMPackage / CaseApplications
MB-S
https://www.meritekusa.com/wp-content/uploads/2025/06/Meritek_Spec-Bridge-Rectifier-MB-S-series-5b-250401-1.pdf
Single-Phase
50V, 100V, 200V, 400V, 600V, 800V, 1000V
0.8A
1.0V
30A
MD-S
General Purpos
DB15-S
https://www.meritekusa.com/wp-content/uploads/2018/06/Single-Phase-Bridge-Rectifier-1.5A-SMD-DIP-S-DB15-S-Series.pdf
Single-Phase
50V, 100V, 200V, 400V, 600V, 800V, 1000V
1.5A
1.1V
50A
SOD-123
General Purpose
DB10-S
https://www.meritekusa.com/wp-content/uploads/2018/06/Single-Phase-Bridge-Rectifier-1.0A-SMD-DIP-S-DB10-S-Series.pdf
Single-Phase
50V, 100V, 200V, 400V, 600V, 800V, 1000V
1A
1.1V
50A
SOD-123
General Purpose
B-S
https://www.meritekusa.com/wp-content/uploads/2018/06/Single-Phase-Bridge-Rectifier-0.5A-SMD-MDI-B-S-Series.pdf
Single-Phase
50V, 100V, 200V, 400V, 600V, 800V, 1000V
0.8A
1.1V
30A
SMD MDI
General Purpose
ABS12~ABS110
https://www.meritekusa.com/wp-content/uploads/2022/09/Single-phase-bridge-rectifier-ABS1XX_DS.pdf
Single-Phase
50V, 100V, 200V, 400V, 600V, 800V, 1000V
1A
1.05V
30A
4-SMD
General Purpose
