Part Number
|
MVR07D121K
|
|
Description
|
120V 1200A Varistor 1 Circuit Through Hole Disc 7mm 7.8J Straight Leads
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
UL/cUL No:E326004, VDE No:40013638
|
Product Characteristics
| Varistor DC Voltage (@1mA) | 120V (108~132) |
| Allowablle Voltage (VACrms) – max. | 75Vac |
| Allowablle Voltage (VDC) – max. | 100Vdc |
| Withstanding Surge Current | 1200A |
| Operating Temperature | -40 ~ +105 degC |
| Storage Temperature | -40 ~ +125 degC |
| Disc Size | 7mm |
| Application | General Purpose |
| Lead Style | Straight |
| Clamping Voltage – max. | 200V |
| Energy (@10/1Kus) – max. | 7.8J |
| Typical Capacitance (@1KHz) | 420pF |
| Diameter (mm) – max. | 9mm |
| Thickness (mm) – max. | 4.5mm |
| Lead Space (mm) | 5mm |
| Series | MVR |
| Packaging | Bulk |
| Part Status | Active |
