Part Number
|
SIM02100YA5038
|
|
Description
|
10ohms +/-25% DCR 0.05ohms Ferrite Bead
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
| Impedance | 10ohms |
| Tolerance | +/-25% |
| Test Frequency | 100MHz |
| DCR Max | 0.05ohms |
| Operating Temperature | -55 ~ +125 degC |
| Package / Case | 0402 |
| Applications | General Type |
| Mounting Type | Surface Mount |
| Rated Current | 500mA |
| Dimension | 1.0mmx0.5mm |
| Thickness | 0.5mm |
| Peak Temperature | 260 degC |
| Reflow Temperature | 230 degC |
| Reflow times | 3 times Max |
| Features | Noise reduction solution for Signal Line |
| Series | SIM02-38 |
| Packaging | Tape and Reel |
| Part Status | Active |
