Part Number
|
SIM00121YA2233
|
|
Description
|
120Ohms +/-25% DCR 0.60Ohms Ferrite Bead
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
| Impedance | 120Ohms |
| Tolerance | +/-25% |
| DCR Max | 0.60Ohms |
| Dimension | 0.4mm X 0.2mm |
| Operating Temperature | -40DegC ~ +125DegC |
| Package / Case | 1005 |
| Applications | Noise reduction solution for Signal Line |
| Mounting Type | Surface Mount |
| Rated Current | 220mA |
| Thickness | 0.20mm +/- 0.02mm |
| Solderability | 245DegC +/- 5DegC |
| Peak Temperature | 260DegC |
| Reel Diameter | – |
| SPQ | – |
| Features | Closed Magnetic Circuit Avoids Crosstalk |
| Series | SIM00-33 |
| Packaging | Tape and Reel |
| Part Status | Active |
