Part Number
|
MXJFHJI40M0
|
Description
|
HC49S 20pF 30/50ppm -40/85C 40MHz
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
Additional Information
|
|
Product Characteristics
Frequency | 40.0MHz |
Load Capacitance | 20pF |
Frequency Tolerance | +/-30ppm |
Frequency Stability | +/-50ppm |
Operating Temperature | -40/85C |
Storage Temperature | -55/125C |
Package / Case | HC-49SMD |
Applications | Wired Network, Mobile Communication, WiMAX, WLAN, Test Equipment |
Mounting Type | Surface Mount |
ESR – max. | 80ohm |
Drive Level – max. | 1mW |
Insulation Resistance (@100Vdc +/-15V) ? min | 500Mohm |
Operating Mode | Fundamental, 3rd OT |
Lead Style | |
Dimensions | 11.40mm x 4.70mm x 4.20mm |
Series | MXJ |
Packaging | Tape and Reel/Ammo |
Part Status | Active |
