Part Number
|
PEHA35V471M0820
|
|
Description
|
470uF 20mohm 0820 Conductive Polymer Capacitor
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
| Capacitance (uF) | 470 |
| Tolerance | +/-20% |
| Voltage (VDC) – Rated | 35 |
| Max ESR (mohm) @100kHz | 20 |
| Operating Temperature | -55 ~ 105 degC |
| Package / Case | 0820 |
| Applications | General Purpose |
| Mounting Type | Through Hole |
| Dissipation Factor (Tangent) max @20degC 120Hz | 0.12 |
| Leakage Current (uA) Max. | 3290 |
| Ripple Current (mArms) @100kHz | 4400 |
| Size / Dimension | 8.0(dia.)x20.0mm |
| Leaded Type | Radial Leaded |
| Features | – |
| Ratings | 5000 Hours @ 105 degC |
| Series | PEHA |
| Packaging | Bulk |
| Part Status | Active |
