Series Number
CSM
Description
Thick Film Chip Resistors – Current Sensing Type
Lead Free Status / RoHS Status
Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Additional Information

Product Characteristics

Resistance 10~100mΩ
Tolerance ±0.5%, ±1%, ±2%, ±5%
Power (Watts) 1/4, 1/2, 3/4, 1.0W
Temperature Coefficient ±50, 100PPM/°C
Operating Temperature -55 ~ 155°C
Package / Case 0805, 1206, 2010, 2512
Applications General Purpose
Mounting Type Surface Mount
Size / Dimension
Height – Seated (Max)
Thickness (Max)
Lead Spacing
Lead Style
Features Current Sensing Type
Composition Thick Film
Series CSM
Packaging Tape and Reel
Part Status Active
