Series Number
|
MXTQ
|
Description
|
32.768 kHz Crystal 4-SOJ Surface Mount
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
Additional Information
|
–
|
Product Characteristics
Frequency | 32.768 kHz |
Load Capacitance | 6, 12.5pF |
Frequency Tolerance | +/-10, +/-20, +/-30ppm |
Frequency Stability | – |
Operating Temperature | -40 ~ +85 degC |
Storage Temperature | -55 ~ +125 degC |
Package / Case | 8.0×3.8×2.5mm |
Applications | Wired Network, Mobile Communication, WiMAX, WLAN, Hand-held Electronic Devices, Computer Clock |
Mounting Type | Surface Mount |
ESR – max. | 50kohm |
Drive Level – max. | 1.0uW |
Insulation Resistance (@100Vdc +/-15V) – min. | 500Mohm |
Operating Mode | Fundamental |
Lead Style | 5.5mm Pitch |
Dimensions | 8.00mm x 3.80mm x 2.50mm |
Series | MXTQ |
Packaging | Tape and Reel |
Part Status | Active |
