Part Number
|
TPV34T911KF
|
|
Description
|
910V 40KA Thermal Varistor 1 Circuit Through Hole Disc 34mm 3-Leads
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
UL/cUL Safety Approval: E326004
|
Product Characteristics
| Varistor DC Voltage (@1mA) | 910V (819~1001) |
| Allowablle Voltage (VACrms) – max. | 550Vac |
| Allowablle Voltage (VDC) – max. | 745Vdc |
| Withstanding Surge Current | 40KA |
| Operating Temperature | -55 ~ +85 degC |
| Terminals | 3-Leads |
| Disc Size | 34mm |
| Application | General Purpose, Thermally Protected |
| Lead Style | Formed Tabs |
| Clamping Voltage – max. | 1500V |
| Energy (@10/1Kus) – max. | 1345J |
| Typical Capacitance (@1KHz) | 1300pF |
| Width (mm) – max. | 40mm |
| Thickness (mm) – max. | 20mm |
| Lead Space (mm) | 23.5mm |
| Series | TPV |
| Packaging | Bulk |
| Part Status | Active |
