Series Number
|
SIM05-M33
|
|
Description
|
Ferrite Chip Bead SMD – AECQ200
|
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
AEC-Q200 Qualified
|
Product Characteristics
| Impedance | 11 ~ 2000Ohm |
| Tolerance | +/-25% |
| DC Resistance (Max.) | 0.10 ~ 0.60Ohm |
| Rated Current (Max.) | 250 ~ 900mA |
| Operating Temperature | -55 ~ +150 degC |
| Package / Case | 0805 |
| Applications | AEC-Q200, Automotive |
| Mounting Type | Surface Mount |
| Size / Dimension | – |
| Thickness (Max) | 0.85mm +/- 0.20mm |
| Test Frequency | – |
| Rating | AECQ200 |
| Features | Excellent Solderability and Heat Resistance |
| Reel Size | 7 Inches |
| Qty Per Reel (pcs) | 4,000 |
| Series | SIM05-M33 |
| Packaging | Tape and Reel |
| Part Status | Active |
