Series Number
|
SIM05-32
|
Description
|
Ferrite Chip Bead High Current Type SMD
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
Additional Information
|
–
|
Product Characteristics
Impedance | 30 ~ 600Ω |
Tolerance | +/-25% |
DC Resistance (Max.) | 0.04 ~ 0.2Ω |
Rated Current (Max.) | 1000 ~ 3000mA |
Operating Temperature | -40 ~ +125 °C |
Package / Case | 0805 |
Applications | General Purpose |
Mounting Type | Surface Mount |
Size / Dimension | 2.0×1.25mm |
Thickness (Max) | – |
Test Frequency | 100MHz |
Rating | High Current Type |
Features | Excellent Solderability and Heat Resistance |
Reel Size | 7 inches |
Qty Per Reel (pcs) | 4,000 |
Series | SIM05-32 |
Packaging | Tape and Reel |
Part Status | Active |
