Series Number
|
SREL-A
|
Description
|
AEC-Q200 Compliant
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
Additional Information
|
–
|
Product Characteristics
Capacitance | 1 ~ 1000uF |
Tolerance | 20% |
Voltage – Rated | 6.3, 10, 16, 25, 35, 50V |
Lifetime @ Temp | 3000 Hours @ 105 °C, 5000 Hours @ 105 °C |
Operating Temperature | -55 ~ 105 °C |
Package / Case | Radial Can |
Applications | AEC-Q200 |
Mounting Type | Surface Mount |
Size / Dimension | Diameter: 4.0 ~ 6.3mm, 8.0 ~10.0mm |
Height – Seated (Max) | (See specsheet) |
Thickness (Max) | (See specsheet) |
Lead Spacing | (See specsheet) |
Case Size DxL (mm) | 4×5.4, 5×5.4, 6.3×5.4, 6.3×7.7, 8×6.2, 8×10.2, 10×10.2 |
Features | General Purpose |
Series | SREL-A |
Packaging | Tape Reel |
Load life | 105°C |
Part Status | Active |
