Series Number
|
SNP-A
|
|
Description
|
AEC-Q200 Compliant, Low Profile Construction Design, 5.5mm Height |
|
Lead Free Status / RoHS Status
|
Lead free / RoHS Compliant
|
|
Moisture Sensitivity Level (MSL)
|
1 (Unlimited)
|
|
Additional Information
|
–
|
Product Characteristics
| Capacitance | 1 ~ 470uF |
| Tolerance | 20% |
| Voltage – Rated | 6.3, 10, 16, 25, 35, 50V |
| Lifetime @ Temp | 2000 Hours @ 85°C |
| Operating Temperature | -40 ~ 85°C |
| Package / Case | Radial Can |
| Applications | AEC-Q200 |
| Mounting Type | Surface Mount |
| Size / Dimension | Diameter: 4.0 ~6.3mm |
| Height – Seated (Max) | 5.5mm |
| Thickness (Max) | – |
| Lead Spacing | (see datasheet) |
| Case Size DxL (mm) | 4×5.4, 4×5.8, 5×5.4, 5×5.8, 6.3×5.4, 6.3×5.8, 6.3×7.7, 8×6.2, 8×10.2, 10×10.2 |
| Features | Non-Polar |
| Load Life | 2000 Hours @ 85°C |
| Series | SNP-A |
| Packaging | Tape and Reel |
| Part Status | Active |
